A regulation full basketball court measures 94 feet by 50 feet (28.65 m by 15.24 m), with rims set at 10 feet (3.05 m) above the floor, according to Wikipedia. A half-court runs from the division line to the end line, while an official 3x3 court measures a separate 15 m by 11 m, according to Playfield Atlas. Clearance space and surface type both shape what you can actually build on your site.

TL;DR:

  • An official 3x3 layout measures 15 by 11 meters, while its recommended footprint is 18 by 14 meters; it is not simply half a court.
  • Indoor builds need at least 25 feet of ceiling clearance, and every boundary needs unobstructed space; do not trade that buffer for extra court length.
  • Before painting permanent lines, check the rules for your competition level: lane width varies slightly, and international markings are 5 centimeters wide.
  • Orient outdoor courts north to south to reduce sun glare, and add a slight grade for drainage on concrete or asphalt surfaces.
  • Some older U.S. high school gyms are only 84 feet long, so measure existing facilities before assuming they meet the current 94 foot standard.
Hoop Mentality
Build Better Basketball Practices
Explore practical coaching resources, including practice plans, drills, and playbooks, designed to help coaches organize practices and prepare teams.

Table of Contents

Standard court dimension reference: full, half, and common variants

Picking the right footprint starts with knowing which standard applies to your situation. A regulation full court is 94 feet by 50 feet (28.65 m by 15.24 m), with rims fixed at 10 feet (3.05 m), a height that stays constant across every format covered here, according to Wikipedia. Some older high school gyms in the United States use an 84-foot length instead, so measure before you assume your existing gym matches current regulation length.

A half-court layout runs from the division line (midcourt) to the end line, giving you roughly half the full-court area, enough for shooting drills, pickup games, and most youth practices. An official 3x3 court is its own standard, not simply “half a court”: it measures 15 m by 11 m (49 ft 2.6 in by 36 ft 1.1 in), covering about 1,776 square feet, against roughly 2,350 square feet for a typical full-court half, according to Playfield Atlas. The 3x3 format keeps the same rim height and reuses lane and restricted-area geometry from full-court rules, so do not assume a half-court diagram will double as a 3x3 layout.

Layout Dimensions (feet) Dimensions (metric) Typical use
Full court 94 ft x 50 ft 28.65 m x 15.24 m Regulation games, high school and above
Older HS variant 84 ft x 50 ft 25.6 m x 15.24 m Some existing US gyms
Half court 47 ft x 50 ft 14.33 m x 15.24 m Practice, pickup, home courts
3x3 court 49 ft 2.6 in x 36 ft 1.1 in 15 m x 11 m 3x3 competition
3x3 recommended footprint 59 ft x 46 ft 18 m x 14 m 3x3 with clearance

For a compact or home setup, work backward from the space you actually have:

  • A half-court with 10 feet of clear space on each side fits comfortably in many backyard or driveway layouts.
  • A 3x3 court needs less width than a full half-court lane-to-lane setup, making it a practical choice for tighter lots.
  • Any compact layout should still preserve full rim height and lane width so shooting mechanics and spacing habits carry over to a regulation court.

Court lines and marked areas explained

Every line on a basketball court has a specific measurement and a specific job, and getting these wrong is the most common layout mistake on home and multi-use courts. The restricted-area arc, which marks the no-charge zone under the basket, has a radius of 1.30 m (about 4 feet) depending on which rule set you follow, according to FIBA’s 2026 rules. The free-throw line sits a fixed distance from the backboard, and the key (the painted lane) has a standard width that varies slightly between rule sets, so check the rulebook for your level before painting anything permanent.

Line widths matter more than most builders expect: official court markings typically use lines 5 cm wide in international rules, and consistent width across the court keeps the layout legible from a distance, according to FIBA’s official rules.

Key marks to include, and how to think about each:

  • The three-point arc has a main-arc distance and a shorter corner distance, both of which must be measured from the exact center of the basket, not the backboard.
  • The center circle marks the start of every jump ball and sits at the exact midpoint of the division line.
  • Lane-space marks (also called hash marks or blocks) line the free-throw lane and set rebounding positions during free throws.
  • The restricted-area arc under the basket is part of the official playing court, while any logo, sponsor mark, or team branding at center court is purely decorative and carries no rule significance.
  • Sidelines and baselines define the full out-of-bounds boundary and should be painted in a color that contrasts clearly against the playing surface.

Use a contrasting color for boundary lines against your surface (white on dark asphalt, dark blue or black on light concrete) so players can track position at full speed without staring at the floor.

Practical layout and site planning

Lines on paper only matter once the surrounding space supports safe, full-speed play. Facility guidance recommends unobstructed clear space outside every sideline and end line, plus a ceiling height of at least 25 feet above the playing surface, according to the 2025-26 NAIA rules book. Where you cannot add that much clearance, a contrasting out-of-bounds belt around the court preserves the boundary visually without requiring extra paint or space.

Work through site planning in this order:

  1. Confirm ceiling height first. Indoor builds need at least 25 feet of clearance above the court for shots and lighting fixtures.
  2. Measure and mark clear space beyond every boundary line before you pour or paint anything, since this space absorbs player momentum and prevents collisions with walls or fencing.
  3. Choose your surface. Indoor courts typically use polished maple, while outdoor courts use concrete or asphalt, each with different rebound and maintenance characteristics, according to Wikipedia.
  4. Orient outdoor courts north-south where possible to reduce sun glare during games, and grade the surface slightly for drainage.
  5. Check for site obstructions (overhead wires, low eaves, drainage grates) before finalizing your footprint.

Pro Tip: If your lot forces a tradeoff, sacrifice total length before you sacrifice ceiling height or boundary clearance: a slightly short court is playable, a low ceiling is not.

Coach-tested resources and templates from Hoop Mentality

Planning a layout on paper gets easier with the right templates in hand. These resources are designed around real practice sessions, not just rulebook geometry, so they translate directly into usable sessions once the paint dries.

— Dejan

Backboard and support structure placement

The backboard sits a fixed distance from the baseline, with the rim projecting out from the board at the regulation 10-foot height used across every layout in this guide, according to Wikipedia. Support structures, whether wall-mounted, ceiling-suspended, or freestanding with a rear base, need to clear the restricted-area arc and the full lane width without any post or base intruding into live playing space.

Hoop placement and court clearance diagram

Freestanding systems need a stable footprint set back far enough that the base and padding stay outside the baseline clearance zone, not just outside the painted lines. Wall-mounted systems need enough wall-to-baseline distance to match standard backboard placement, which is a common error in converted gyms and garages where the wall sits closer than the rulebook distance allows.

Padding on the support structure and base matters as much as placement. Facility guidance recommends padding on backboard supports and nearby walls, since players drive hard into that zone during layups and rebounds, according to NAIA facility guidance. For outdoor or multi-use installations, check that the support base does not sit inside your planned clear-space buffer: a backboard pole positioned too close to the baseline defeats the purpose of the clearance you measured earlier in your layout.

Bench and scorer’s table placement

Team benches and the scorer’s table sit along the sideline opposite the main spectator side, positioned outside the court’s out-of-bounds line but within the facility’s overall clear-space zone. This placement keeps substitutions, timeouts, and scoring operations within easy reach of the court without encroaching on live playing space.

The scorer’s table typically centers on the division line, giving officials a clear view of both baskets and keeping the game clock, scoreboard controls, and book equidistant from each team’s bench. Team benches extend outward from the scorer’s table on each side, each positioned closer to its own basket for the second half, which is standard practice at most competition levels.

For smaller or multi-use facilities, bench and table placement often gets compressed into the minimum clear-space buffer rather than a dedicated spectator-free zone. If your site cannot support a full dedicated bench area, prioritize keeping the scorer’s table and benches clear of the baseline extension lines first, since officials and substitutes crossing into live play create the most common game-day safety issue.

Court lighting considerations

Lighting affects shooting accuracy and depth perception more than most layout planners expect, particularly for perimeter shots where players track the ball against the ceiling or sky. Indoor courts need even, glare-free lighting across the full playing surface, including the corners near the three-point arc where shadows from support structures or low fixtures commonly interfere with sightlines.

Outdoor courts face a different challenge: sun position changes throughout the day, so orienting the court north-south, as covered in the site-planning section above, reduces the hours where players shoot directly into glare. For courts used into the evening, add fixtures high enough to clear backboard support structures and bright enough to reach the corners, not just center court, since corner three-point shooters need the same visibility as players near the rim.

Avoid mounting lights directly behind either basket at a low angle, since that position puts the light source directly in a shooter’s line of sight on free throws and perimeter attempts. For multi-use gyms, dimmable or zoned lighting lets you light a half-court practice session without running full-court fixtures, which also reduces energy costs during smaller sessions.

Layout modifications for portable and multi-use courts

Portable hoop systems and multi-use flooring let you run basketball sessions on surfaces also used for other sports, but they require a few layout adjustments compared to a dedicated court. Portable backboard systems need a wider base footprint for stability, so your clear-space buffer around that corner of the court should account for the base, not just the standard support-pole clearance used in permanent installations.

Multi-use gym floors often carry overlapping lines for basketball, volleyball, and other sports, so basketball lines need a distinct color or dash pattern to stay legible among the others. Where a full basketball layout will not fit alongside other sport markings, many facilities paint only the half-court or 3x3 footprint and skip full-court lines entirely, reserving full-court layouts for events that need them.

Blank Basketball Court Diagram For Drawing Plays (Printable)

For true multi-use planning, mark the restricted-area arc and free-throw lane in a color that reads clearly regardless of which other sport’s lines cross through that zone, since that area sees the heaviest player traffic. Portable or foldaway hoop systems should still meet the regulation 10-foot rim height when deployed, even if the surrounding floor markings are temporary or simplified for a shared-use space.

The one rule that matters more than exact dimensions

If you cannot hit a regulation footprint, protect two things above everything else: unobstructed clear space around the court and a true 10-foot rim. A slightly shorter or narrower court still teaches real spacing and shot mechanics; a cramped sideline or a mismeasured rim height does not.

Plan for a full regulation court when you are building for competitive teams working toward games at that level. Accept a compact layout for youth development, home practice, or casual play, as long as clearance and rim height stay accurate.

— Dejan

Plan your court with Hoop Mentality’s coaching resources

Once your lines are measured and your rim is set, the next step is putting that court to work. Our blank basketball court diagram gives you a printable reference for drawing plays and confirming layout before anything gets painted permanently.

Blank Basketball Court Diagram For Drawing Plays (Printable)

Browse our full basketball templates collection to get every tool in one place.

FAQ

How many square feet do you need for a full-size basketball court?

A regulation full court measures 94 feet by 50 feet, which comes out to 4,700 square feet of playing surface, according to Wikipedia. Add recommended clear space on all sides, and your total site footprint needs to run larger than the painted court itself.

Is the rim 12 feet off the ground?

No, the rim is set at 10 feet (3.05 m) above the floor, a height that applies across full courts, half courts, and 3x3 layouts alike, according to Wikipedia. This height stays constant regardless of which court format or competition level you are building for.

Is a basketball size 7 a full-size ball?

Ball size varies depending on competition level and governing body, and is a separate specification from court layout, so check your governing body’s equipment rules alongside the court dimensions in this guide.

What is the top of the key in basketball?

The “top of the key” refers to the area at the edge of the free-throw circle, farthest from the basket, where the free-throw line meets the semicircle. It is a common reference point for player positioning and shot location, including on shot chart templates used to track scoring zones.
